Electronic Specifications
- Power Output per Channel
- 300W @ 2, 4 or 8 Ohms
- Number of Channels
- 1
- Total Harmonic Distortion
- 0.5% maximum harmonic distortion at any power level from 250 milliwatts to rated power, 20Hz to 20,000Hz
(≤ 0.25% harmonic distortion at 1kHz)
- S/N below rated output
- 117dB
- Dynamic Headroom
- 1.2dB
- Damping Factor
- >15 Wideband
- Rated Power Band
- 20Hz to 20kHz
- Frequency Response
- +0, -0.5dB from 20Hz to 20,000Hz
+0, -3.0dB from 10Hz to 100,000Hz
Control
- Remote Power Control
- Yes
- Multi-Channel DB25 Cable
- N/A
General Specifications
- Circuit Configuration
- Quad Balanced, Unity Coupled
- Circuit Design
- Vacuum Tube
- Mono Bridge
- No
- Mono Parallel
- No
- Output Type
- Unity Coupled Output Transformer
- Meters
- Yes
- Meter Light Switch
- Yes
- Balanced Input
- Yes
- Front Panel
- 1/2" Glass with handles
- Illumination
- LED Fiber Optic
- Chassis Style
- Open Stainless Steel
Connectivity
- Speaker Binding Post Type
- Yes, 200 amp, 3-way
Weights & Dimensions
- Dimensions (W x H x D)
- 17-3/4" (45.09cm) x 12-5/16" (31.27cm) (including feet) x 23" (58.42cm) (including front panel and cables)
- Weight
- 116 lbs (52.6 kg)
- Shipping Weight
- 141 lbs (63.9 kg)
